Groundwater and surface-water interactions in the Lower Duwamish Waterway, Seattle, Washington

The U.S. Geological Survey (USGS), in cooperation with the Washington State Department of Ecology (Ecology), conducted a study to describe the current understanding of the regional groundwater system of the lower Duwamish River valley and groundwater and surface-water interactions in the lower Duwamish Waterway. The lower Duwamish Waterway is the final 5-mile (mi) reach of the Duwamish River before it empties into Elliott Bay in Puget Sound near Seattle, Washington. A nearshore site (hereinafter referred to as “Nearshore Site” to distinguish the particular site from general discussions of nearshore areas) along the western shoreline of the Duwamish River, about 1.5 mi upstream from the river mouth, was selected for focused groundwater data collection by USGS. Data loggers were deployed in seven groundwater wells and one stilling well in the Duwamish River to measure specific conductance, temperature, and depth at 15-minute intervals for a period of about 2 years.

At the Nearshore Site during 2020–22, water levels in the shallow wells were 3–8 feet (ft) higher than water levels in the deep wells, providing evidence for a low-permeability layer between the shallow and deep aquifers in this area. The shallow wells had a pronounced seasonal variability, with high water levels in winter and low water levels in summer. Data from the deep wells showed far less seasonal variability, with slight increases in winter and a near-constant water level from spring to autumn. The deep wells had a strong hydraulic connection to the Duwamish River, as evidenced by the synchronous water-level variability during the tidal cycle, whereas the shallow wells had minimal to no tidal response. The potentiometric maps developed for the Nearshore Site and surrounding areas indicate large differences in groundwater-flow directions for the shallow and deep aquifers at low and high tides. For the shallow aquifer, flow is toward the lower Duwamish Waterway near the Nearshore Site, regardless of the tidal condition. For the deep aquifer, a potentiometric trough forms parallel to the shoreline during high tide, indicating that groundwater flow converges from the uplands to the west and the Duwamish River to the east. The geometry of the potentiometric surfaces between the nearshore-most well and the shoreline is complex and is further confounded by intermittent shoreline armoring and other buried infrastructure, which could serve as either a barrier or a conduit to flow.

Groundwater and surface-water interactions in the lower Duwamish Waterway are inherently complex as a result of three overarching factors. First, water levels in the lower reaches of the Duwamish River vary daily by 11–16 ft because of tides from Puget Sound, which create large swings in the hydraulic gradient in the nearshore groundwater system. Second, the density and chemical composition of water in the Duwamish River change daily with the tides and seasonally, which constrains how river water entering the nearshore sediments interacts with discharging groundwater. Third, the nearshore subsurface and shoreline conditions are heterogenous because of extensive shoreline armoring over the past century, which governs the flow of groundwater and infiltrating river water. These unique features of groundwater and surface-water interactions in the lower Duwamish Waterway thus govern the transport of terrestrial contaminants to the lower Duwamish Waterway. Furthermore, the heterogenous aquifer properties in the lower Duwamish Waterway contribute to spatially and temporally dynamic contaminant-transport processes.
