A methodology to estimate CO2 and energy gas storage resources in depleted conventional gas reservoirs

Depleted hydrocarbon reservoirs are subsurface geological structures capable of sequestering vast quantities of carbon dioxide (CO₂) as well as storing other energy gases for later usage, such as natural gas, and potentially hydrogen (H₂). Here we outline a methodology to quantify multi-gas storage resources in depleted conventional gas reservoirs for usage in assessments by the United States Geological Survey (USGS) at the scale of sedimentary basins. The methodology consists first of quantifying accessible pore volume in a depleted reservoir for natural gas storage using up to three equations. Input data are derived from commonly reported or estimated reservoir parameters and natural gas production volumes, and equations may be combined in linear models to improve pore volume estimates. Storage estimates from these equations are tested and validated for 31 reservoirs in the Michigan Basin Province, USA that were previously converted to underground gas storage facilities and have known (federally reported) natural gas storage capacities. Secondly, natural gas storage capacities can be transformed via fluid substitution calculations to estimate the storage resources for non-native fluids, applied here for, CO₂, H₂, and methane-H₂ blends, accounting for molecule-specific deviations from ideal gas behavior at reservoir pressures and temperatures as well as differing storage efficiencies. Importantly, the storage of non-native fluids may not be appropriate in all depleted gas reservoir settings due to potential risks like leakage, in particular in the case of H₂ storage, requiring additional knowledge of caprock sealing capacity. Given this caveat, we demonstrate the fluid substitution method for natural gas reservoirs of the Northern Niagaran Reef and Southern Niagaran Reef USGS plays in the Michigan Basin Province, as these trends of Silurian pinnacle reefs are capped with tight-sealing evaporite facies. The deterministic equations outlined from this methodology can be incorporated into future probabilistic USGS gas storage assessments for CO₂, H₂, and natural gas resources in the United States.
