Maps showing coal resources of the Crumpler quadrangle, Mercer, McDowell, and Wyoming Counties, West Virginia

Coal Geology

The Crumpler quadrangle lies in the Appalachian Plateaus province, with the coal bearing Pocahontas and New River Formations of Pennsylvanian age having a gentle dip toward the northwest. Coal bed maps were prepared (figures 1-7) and resources were estimated (table 1) for seven of the many coal beds in the Crumpler quadrangle (Stricker, 1980, lists the names of the various coal beds in the quadrangle) following methods established by U.S. Bureau of Mines and U.S. Geological Survey, 1976. All of these coal beds crop out at the surface in the quadrangle, have a maximum thickness thickness of over-burden of less than 300 meters, and have been mined at the surface, or under-ground, or both. Resource estimates were not calculated for other coal beds in the Pocahontas and New River Formations, either because of insufficient data of because of the beds are too thin. Figure 8 is a generalized stratigraphic column of the coal-bearing sequence in the Crumpler quadrangle showing thickness and relative positions of the various coal beds. The Crumpler quadrangle originally contained about 498 million metric tons of coal. Approximately 326 million metric tons have been mined, or lost in mining, leaving remaining resources of 172 million metric tons.

Analyses of the mined coal beds in the Crumpler and adjacent quadrangle show the coal is medium - to low volatile bituminous (most are low volatile bituminous), containing 14-27 percent volatile matter (with an arithmetic mean of 18 percent), 2.1-22.4 percent ash (with an arithmetic mean of 7 percent), and 0.5-1.8 percent total sulfur (with an arithmetic mean of 0.8 percent). Heating values range from 6,380 to 8,610 Kcal/kg on an as-received basis. Trace element and major and minor oxide composition, of both whole coal and laboratory ash, for 59 samples within or near the quadrangle were obtained from USCHEM (Geochemical Data File or National Coal Resources Data System), (Kozey and others, 1980.) Neither elements of environmental concern such as arsenic, lead, mercury, and selenium nor potentially valuable elements such as germanium, uranium and thorium were found in significant amounts in the coal.
