Assessment of water levels, nitrate, and arsenic in the Carson Valley Alluvial Aquifer and the development of a data visualization tool for the Carson River Basin, Nevada

Residents of Carson Valley, Douglas County, Nevada, rely on the basin-fill alluvial aquifer underlying the valley for drinking water. Since the 1980s, groundwater levels and water-quality data have been collected to monitor the status of the aquifer system and to assist in planning efforts to address current (2024) and future demand. The U.S. Geological Survey (USGS), in cooperation with Douglas County, Nevada, evaluated trends in water levels, nitrate, and arsenic concentrations from a network of monitoring and domestic wells in Carson Valley. This work also assessed the monitoring well network to determine the suitability of wells for characterizing the occurrence of arsenic in the groundwater. Monitoring of constituents, such as nitrate and arsenic concentrations, is needed to assess changes in contaminant distribution and to evaluate the effect that changing land use and groundwater pumping has on their occurrence and transport.

Results of the trend analysis indicate water levels are declining (p<0.05) in 17 of 26 selected monitoring wells (65 percent). Areas with the largest change in water levels, with more than 20 feet of declines, were within the community areas of Johnson Lane, Ruhenstroth, South Agricultural, East Valley, and Fish Springs. Variations in water levels measured in wells from the Central Agricultural, Minden, Foothill, Alpine County (one well), and Gardnerville Ranchos areas show periods of increase and decrease over time, but they also maintain long-term declining trends (p<0.05).

Increases in nitrate concentrations in groundwater samples collected from 9 out of 14 selected monitoring wells (64 percent) are statistically significant (p<0.05) within the Ruhenstroth, Gardnerville Ranchos, East Valley, Genoa, and Johnson Lane community areas. Samples collected from a well in Indian Hills/Jacks Valley indicated a decreasing trend in nitrate concentration over time. Nitrate concentrations in samples collected from wells in East Valley, Genoa, Johnson Lane, and Indian Hills/Jack Valley were consistently low (less than 3 milligrams per liter [mg/L]) and stable. Nitrate concentrations from selected wells in Johnson Lane and Garnerville Ranchos exceeded the U.S. Environmental Protection Agency (EPA) maximum contaminant level (MCL) of 10 mg/L (as nitrogen) and have trends that are increasing over time. In 2022, a sample collected from Johnson Lane had a concentration (7.3 mg/L) below the MCL with an increasing trend over time.

Temporal trend analyses for groundwater arsenic concentrations in Carson Valley could not be done because of a lack of temporal data. However, using available historical data, arsenic concentrations seem to be greater in groundwater from wells located on the eastern and northern areas of the valley than in wells located on the western or southern areas. Groundwater arsenic concentrations exceed 5 micrograms per liter (μg/L) in most samples collected from wells in Johnson Lane, Airport, Central Agricultural, and East Valley areas and in many cases exceed the U.S. Environmental Protection Agency (EPA) MCL of 10 μg/L. Data indicate that groundwater from domestic wells screened at deeper intervals are likely more vulnerable to elevated arsenic concentrations than shallower wells.

A groundwater network evaluation for Carson Valley identified potential modifications in the sampling locations and frequency to better understand the effect of groundwater pumping in communities where municipal and domestic demand are greatest, potentially enhancing understanding of contaminant transport in these areas. Potential modifications to the active well network include reducing the frequency of sample collection from existing network wells (6 out of 11) that have consistently shown low and stable nitrate concentrations, adding wells in areas where data are sparse, and increasing the number of wells in areas with elevated groundwater nitrate concentrations. Including the analysis of arsenic in samples from the active groundwater monitoring well network will provide more detail on the temporal and spatial variability of arsenic concentrations.

A visualization tool for the Carson River Basin was developed to provide access to discrete and near real-time hydrologic and water-quality data. The Carson River Basin Hydro Mapper (CBH; U.S. Geological Survey, 2023b) shows active and historical discrete water levels measured by the USGS and the State of Nevada Division of Water Resources, discrete groundwater nitrate and arsenic concentration data collected by the USGS, near real-time streamflow, and surface water levels for select waterbodies. The hydrologic data in the CBH provides resource managers, the public, and the scientific community with an easily accessible tool to present and communicate the most up-to-date information available about local and basin-wide water resources.
