As part of a continuing program by the U.S. Geological Survey to collect and chemically analyze representative samples of U.S. coals, 18 samples were collected from the Upper Cretaceous Emery and Ferron Sandstone Members of the Mancos Shale in the Henry Mountains coal field, Wayne and Garfield Counties, Utah (fig. 1). The 18 samples are briefly described in table 1. Thirteen of these samples were collected from seven holes that were drilled in connection with the Henry Mountains EMRIA (Energy Mineral Rehabilitation Inventory and Analyses) study (U.S. Department of the Interior, 1978). The locations of the seven core holes and the four other sampling sites are shown on figure 2.
The Henry Mountains coal field is adjacent to the Henry Mountains of southeastern Utah. The basin is a long, narrow syncline about 110 km long and 24 km wide bounded on the west by the Waterpocket Fold and on the east by the Henry Mountains. The most comprehensive geologic report available on the area is by Hunt and others (1953). Their work included a considerable amount of information on the coal resources. Other work in the area concerning coal or stratigraphy of coal bearing units includes: Doelling (1972), Peterson and Ryder (1975), Doelling (1975), Law (1977; 1978; 1979 a,b), and U.S. Department of the Interior (1978).
In the Henry Mountains field, there are three coal bearing units in rocks of Late Cretaceous age. In ascending order they are the Dakota Sandstone, the Ferron Sandstone Member of the Mancos Shale, and the Emery Sandstone Member of the Mancos Shale. The coal beds of the Henry Mountains coal field originated as layers of peat that were deposited, for the most part, in coastal swamp environments. Individual coal beds are discontinuous and exhibit large variations in thickness and quality. The thickest and most continuous coal beds occur in the Emery Sandstone Member along or near the axis of the Henry Mountains syncline (Law, 1978).
