ERTS-1 digital data in the form of computer compatible tapes provide the geoscientist with an unusual opportunity to test the maximum flexibility of the satellite system using interactive computers, such as the General Electric Image 100 System. Approximately 9 hours of computer and operator time were used to analyze the Lake Titicaca image, 1443-14073, acquired 9 October 1973. The total area of the lake and associate wetlands was calculated and found to be within 3 percent of previous measurements. The area was subdivided by reflectance characteristics employing cluster analysis of all 4 bands and later compared with density values of band 4. Reflectance variations may be attributed to surface roughness, water depth and bottom characteristics, turbidity, and floating matter. Wetland marsh vegetation, vegetation related to ground-water effluents, natural grasses, and farm crops were separated by cluster analysis. Sandstone, limestone, sand dunes, and several volcanic rock types were similarly separated and displayed by assigned colors and extended through the entire scene. Waste dumps of the Matilde Zinc Mine and smaller mine workings were tentatively identified by signature analysis.
Histograms of reflectance values and map printouts were automatically obtained as a record of each of the principal themes. These themes were also stored on a work tape for later display and photographic record as well as to serve in training.
The Image 100 System is rapid, extremely flexible and very useful to the investigator in identifying subtle features that may not be noticed by conventional image analysis. The entire scene, which covers 34,225 km2, was analyzed at a scale of 1:600,000, and portions at 1:98,000 and 1:25,000, during a 9-hour period at a rental cost of $250 per hour. Costs to the user can be reduced by restricting its uses to specific areas, objectives, and procedures, rather than undertaking a complete analysis of a total scene.
