Digital flood-inundation maps for a total of 19.7 miles of the Grand River, the Red Cedar River, and Sycamore Creek were created by the U.S. Geological Survey (USGS) in cooperation with the City of Lansing, Michigan, and the U.S. Army Corps of Engineers. The flood-inundation maps, which can be accessed through the USGS Flood Inundation Mapping Science Web site at http://water.usgs.gov/osw/flood_inundation/, show estimates of the areal extent and depth of flooding corresponding to selected water levels (stages) at three USGS streamgages: Grand River at Lansing, MI (04113000), Red Cedar River at East Lansing, MI (04112500), and Sycamore Creek at Holt Road near Holt, MI (04112850). Near-real-time stages at these streamgages can be obtained on the Internet from the USGS National Water Information System at http://waterdata.usgs.gov/ or the National Weather Service (NWS) Advanced Hydrologic Prediction Service at http:/water.weather.gov/ahps/, which also forecasts flood hydrographs at all of these sites.
Each set of flood profiles was computed by means of a one-dimensional step-backwater model. Each model was calibrated to the current stage-discharge relation at each streamgage and to water levels determined with stage sensors (pressure transducers) temporarily deployed along each stream reach. The hydraulic model was used to compute a set of water-surface profiles for flood stages from nearly Action Stage to above Major Flood stage, as reported by the National Weather Service. The computed water-surface profiles were then used in combination with a Geographic Information System digital elevation model derived from light detection and ranging (lidar) data to delineate the approximate areas flooded at each water level.
These maps, used in conjunction with real-time USGS streamgage data and NWS forecasting, provide critical information to emergency management personnel and the public. This information is used to plan flood response actions, such as evacuations and road closures, as well as aid in postflood recovery efforts.
