Geologic map of Kundelan ore deposits and prospects, Zabul Province, Afghanistan; modified from the 1971 original map compilations of K.I. Litvinenko and others

This map and cross sections are redrafted modified versions of the Geological map of the Kundelan ore deposit area, scale 1:10,000 (graphical supplement no. 18) and the Geological map of the Kundelan deposits, scale 1:2,000 (graphical supplement no. 3) both contained in an unpublished Soviet report by Litvinenko and others (1971) (report no. 0540). The unpublished Soviet report was prepared in cooperation with the Ministry of Mines and Industries of the Royal Government of Afghanistan in Kabul during 1971. This redrafted map and cross sections illustrate the geology of the main Kundelan copper-gold skarn deposit, located within the Kundelan copper and gold area of interest (AOI), Zabul Province, Afghanistan. Areas of interest (AOIs) of non-fuel mineral resources within Afghanistan were first described and defined by Peters and others (2007) and later by the work of Peters and others (2011a). The location of the main Kundelan copper-gold skarn deposit (area of this map) and the Kundelan copper and gold AOI is shown on the index map provided on this map sheet.

The estimated resources of the Kundelan copper-gold skarn deposit are 21,400 metric tons (t) of copper, 1.6 t of gold, and 133.4 t of molybdenum at an average grade of 1.21 weight percent (wt. %) copper (ranging from 0.66 to 4.03 wt. % copper); 0.9 grams per metric ton (g/t) gold (ranging from 0.3 to 3.1 g/t gold); 0.14 wt. % molybdenum; and as much as 10 g/t silver and 0.03 wt. % bismuth (Peters and others, 2011b).

Small past production of gold and base metals is also reported by Douvgal and others (1971) from many prospects within the Kundelan copper and gold AOI. Outside the skarn areas, argillic hydrothermal alteration is present (Abdullah and others, 1977). Most copper and gold prospects in the Kundelan copper and gold AOI are reported to contain commercial-grade ores of copper and (or) gold, and many prospect areas have potential for these commodities to be discovered in commercial volumes. Future initial mine exploration and later development in many of the prospects, and specifically in the Kundelan copper-gold skarn deposit, could result in near-term small- to medium-sized gold mining operations (Peters and others, 2011b).

The redrafted map and cross sections reproduce the topology of rock units, contacts, faults, and so forth, of the original Soviet map and cross sections, and they include modifications based on our examination of these documents and our observations made during a brief field visit in August of 2010. We have attempted to translate the original Russian terminology and rock classifications into modern English geologic usage as literally as possible without changing any genetic or process-oriented implications in the original descriptions. We also use the age designations from the original Soviet maps, except for the phase I and II intrusive igneous rocks. Phase I and II igneous rocks are reassigned an Early Cretaceous age (from lower Paleogene) based on a uranium-lead (U-Pb) zircon SHRIMP analysis from quartz diorite, which yielded an age of 104±1 Ma (mega-annum). The information provided in the description of map units is from both the source report by Litvinenko and others (1971) and the original 1:10,000 scale map (graphical supplement no. 18), also from Litvinenko and others (1971). Because of the poor quality of the original map, some map features could not be identified and some features may be misinterpreted. The rock unit colors used on the redrafted maps and cross sections differ from the colors shown on the original Soviet version. Colors were selected according to the color and pattern scheme of the Commission for the Geological Map of the World (CGMW) at http://www.ccgm.org.

Elevations on the cross sections are derived from the original Soviet topography and may not match the Global Digital Elevation Model (GDEM) topography used on the redrafted map of this report. Most hydrography derived from the Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) has not been included on our redrafted version of the map because of a poor fit with alluvial deposits from the unmodified original Soviet map (graphical supplement no. 18; Litvinenko and others, 1971).
