Geologic setting of the West Flank, a FORGE site adjacent to the Coso geothermal field

The West Flank FORGE (Frontier Observatory for Research in Geothermal Energy) site is located immediately west and outside of the Coso geothermal field, eastern California. Coso is a fluid-dominated, high temperature geothermal system that has been producing power continuously since 1987. The reservoir is composed of highly faulted, fractured and hydrothermally altered Cretaceous and Jurassic plutonic basement rocks. The heat source is a shallow, silicic magma chamber associated with overlying, Quaternary rhyolites and basalts of the Coso volcanic field. Over 30 years of development drilling and associated investigations demonstrates that several well-defined boundaries exist at Coso beyond which there is no commercial, hydrothermal geothermal potential. The West Flank is just west of one of these boundaries and it meets all required FORGE temperature (175-225˚C), host rock (crystalline rock), and depth (1.5-4.0 km) criteria.

It has been hypothesized that the Coso volcanic field exists within a right-releasing step-over between two NW-striking, dextral fault systems. Two distinct fault populations yield high permeability drilling targets in the geothermal field. The first population contains WNW-trending with antithetical, NE-trending strike-slip faults and the second includes N- to NNE-trending normal faults. The West Flank appears to be separated from the geothermal field by one such northerly trending fault bounded by a felsic dike swarm. The West Flank’s 83-11 well suggests that the West Flank is comprised of weakly altered, leucogranite and diorites typical of the Jurassic to Cretaceous basement. The stress field in the West Flank has been rotated to 81˚ in contrast to the minimum principal stress orientations within the geothermal field which range from 103˚ to 108˚. Limited drilling, geophysics and other data sets are being assessed and synthesized to develop a working, 3d conceptual geologic model of the West Flank for FORGE.
