Geology and oil and gas assessment of the Fruitland Total Petroleum System, San Juan Basin, New Mexico and Colorado: Chapter 6 in Geology and Oil and Gas Assessment of the Fruitland Total Petroleum System, San Juan Basin, New Mexico and Colorado

The Fruitland Total Petroleum System (TPS) of the San Juan Basin Province includes all genetically related hydrocarbons generated from coal beds and organic-rich shales in the Cretaceous Fruitland Formation. Coal beds are considered to be the primary source of the hydrocarbons. Potential reservoir rocks in the Fruitland TPS consist of the Upper Cretaceous Pictured Cliffs Sandstone, Fruitland Formation (both sandstone and coal beds), and the Farmington Sandstone Member of the Kirtland Formation, and the Tertiary Ojo Alamo Sandstone, and Animas, Nacimiento, and San Jose Formations.
Analysis of the geochemistry of Fruitland coal-bed gas and co-produced water suggests that hydrocarbons in Fruitland coal beds began to form early in the depositional history of the Fruitland Formation with the generation of early microbial gas. Source rocks in the Fruitland entered the oil generation zone in the late Eocene and continued to generate minor oil and large quantities of thermogenic gas into middle Miocene time. Near the end of the Miocene, thermogenic hydrocarbon generation and subsidence in the San Juan Basin ceased, and the basin was uplifted and differentially eroded. Late-stage (secondary) microbial gas has been documented in Fruitland coal-bed reservoirs and was formed by microbial reduction of carbon dioxide during introduction of groundwater in the late Pliocene and Pleistocene. Most of this late-stage microbial gas is found just downdip from the northern, western, and southern Fruitland outcrops. The northern part of the Fruitland Formation is overpressured as a result of artesian conditions established in the Pliocene or Pleistocene. South and east of the overpressured area, the Fruitland is either normally pressured or underpressured.
Four assessment units (AU) were defined in the Fruitland TPS. Of the four AUs, one consists of conventional gas accumulations and the other three are continuous-type gas accumulations: Tertiary Conventional Gas AU, Pictured Cliffs Continuous Gas AU, Basin Fruitland Coalbed Gas (CBG) AU, and Fruitland Fairway CBG AU. No oil resources that have the potential for additions to reserves in the next 30 years were estimated for this TPS. Gas resources that have the potential for additions to reserves in the next 30 years are estimated at a mean of 29.3 trillion cubic feet of gas (TCFG). Of this amount, 23.58 TCFG will come from coal-bed gas accumulations and 83.1 percent of this total is estimated to come from the Basin Fruitland CBG AU. The remaining 5.72 TCFG is allocated to continuous-type gas accumulations (5.64 TCFG) and conventional gas accumulations (0.08 TCFG). Although the Fruitland Fairway CBG AU has produced the most significant amount of coal-bed gas to date, the area of the AU is limited. New potentially productive wells will come from infill drilling, and the number of these wells will be limited by effective drainage area. Total natural gas liquids (NGL) that have the potential for additions to reserves in the next 30 years are estimated at a mean of 17.76 million barrels. Of this amount, 16.92 million barrels will come from the Pictured Cliffs Continuous Gas AU and the remainder from the Tertiary Conventional Gas AU.
