The area mapped includes most of northwestern Chichagof Island. The work, started in 1946, is a continuation of the geologic mapping done in the adjoining Chichagof mining district by Reed and Coats. The gold-bearing zone recognized by these writers continues through the area mapped by the writer to the northern shore of Chichagof Island.
Stratified rocks ranging in age from Paleozoic through Early Cretaceous were intruded by gabbro, quartz diorite, norite-gabbro, and by younger quartz diorite.
The igneous rocks from oldest to youngest are: gabbro, diorite, quartz diorite, the rocks associated with the nickel deposits, which include gabbro-norite and quartz diorite, and basalt. The diorite is believed to have been formed during Early Cretaceous time, and the gabbro is older by an unknown amount. The gabbro and diorite are believed to be, over large areas, recrystallized older rock. The oldest group of quartz diorite intrusives in places cuts the diorite and is therefore younger. The quartz diorite is minerally somewhat foliated and slightly metamorphosed.
The igneous rocks associated with the nickel deposits are the youngest of the major igneous rock groups. They intruded the Cretaceous graywacke after it had been folded to essentially its present position.
Gold is the most economically important mineral commodity mined to date. The Apex and El Nido are the two largest mines in the area, but some gold has been recovered from the Goldwin and Cobol properties and small amounts from some other small prospects. In addition to gold the area includes nickel-bearing deposits at Mirror Harbor on Chichagof Island and at Bohemia Basin on Yakobi Island. Copper mineralization occurs in the area north of Goulding Harbor.
An attempt has been made to outline areas favorable for prospecting based on the regional geology and, on the number and kind of quartz veins found. In general the best area for prospecting appears to be on a northwest-trending zone which extends from the head Pinta Bay to the northern end of Althorp Peninsula.
