The drilling and logging information provided in this report was collected during September 1980 as part of the Energy Lands program of the
U.S. Geological Survey.
Drill hole 2C-80 is located in the Capps Coal Field, approximately 100 km (62 mi) west of Anchorage, Alaska (fig. 1). The drilling was undertaken to obtain information on the geotechnical characteristics of a part of the coal-bearing Tyonek Formation and overlying surficial deposits. The preliminary results of a previous drill hole (1C-79), located 1.3 km (0.8 mi) northeast of drill hole 2C-80, were reported by Chleborad and others (1980).
The Tyonek Formation is early Oligocene to middle Miocene in age (Wolfe and Tanai, 1980). At the drill site it is overlain by a thin colluvial deposit of Quaternary age.
The drilling and continuous core sampling penetrated 19.5 m (63.9 ft) of overburden, a major coal bed (Waterfall bed), and approximately 29 m (95.1 ft) of underlying material, to a total depth of 61 m (200 ft). Drill hole 2C-80 stratigraphically overlaps drill hole 1C-79 and continues down section approximately 33 m (108 ft).
A proposed open pit coal-mining plan (Placer Amex, Inc., 1977, status report of December 1977) outlines a sequential mining and reclamation scheme for five areas in the Capps Coal Field. Figure 2 shows the location of drill holes 2C-80 and 1C-79 with respect to the proposed mining areas as well as selected surface features. A general description of the geology and natural hazards of the region are given by Schmoll and others (1981).
The generalized lithology interpreted from core obtained from drilling and supplemented by outcrop mapping accomplished during the 1979 and 1980 field seasons is presented in figure 3. A more detailed lithologic log is presented as part of the geotechnical log.
The geotechnical and geophysical logs presented herein (pls. 1 and 2) provide basic physical-property and engineering data useful in predicting the response of geologic materials to proposed large-scale coal mining and related development, and in identifying and assessing potential geologic hazards.
