Response of a 42-storey steel-frame building to the Ms = 7.1 Loma Prieta earthquake

January 1, 1993

A set of 14 acceleration records was obtained from a 42-storey steel-frame building, the Chevron Building, in San Francisco during the Ms= 7.1">Ms= 7.1 Loma Prieta earthquake of 17 October 1989. Data were analysed using a system identification method based on the discretetime linear filtering, and the least-squares estimation techniques. The results show that the response of the building is dominated by two modes: a translational mode in the weaker (southwest-northeast) principal direction of the building at 0.16 Hz with 5% damping, and a translational-torsional mode along the east-west diagonal of the building's cross-section at 0.20 Hz with 7% damping. There are significant contributions from higher modes at 0.54 Hz, 0.62 Hz, 1.02 Hz and 1.09 Hz. All the modes incorporate some torsion, but the amplitudes of torsional components are small, about 10% of translational amplitudes. Soil-structure interaction influences the vibrations near 1.0 Hz. The contribution of soil-structure interaction to the peak displacements of the building is significant, particularly at lower floors.

Publication Year 1993
Title Response of a 42-storey steel-frame building to the Ms = 7.1 Loma Prieta earthquake
DOI 10.1016/0141-0296(93)90059-D
Authors E. Şafak
Publication Type Article
Publication Subtype Journal Article
Series Title Engineering Structures
Index ID 70017915
Record Source USGS Publications Warehouse
