Changes in phosphorus and suspended solids loading in the Fox River, northeastern Wisconsin, 1989–2021

The entire Lower Fox River and inner bay of Green Bay, in northeastern Wisconsin, have been listed as impaired by the Wisconsin Department of Natural Resources (WDNR) for low dissolved oxygen and degraded habitat, with total phosphorus (TP) and total suspended solids (TSS) concentrations listed as the likely causes of these impairments. To restore the Fox River and Green Bay, total maximum daily loads (TMDLs) were developed for TP and TSS, and actions were taken throughout the Fox River Basin to improve water quality. In this study, we estimated concentrations and loads of TP, dissolved phosphorus (DP), and TSS at the Lake Winnebago outlet, De Pere, and the mouth of the Fox River from water year (WY) 1989 to WY 2021; described changes in concentrations and loads through time during this period; and compared the concentrations and loads for the most recent 5-year period (WYs 2017–21) with the WDNR criteria for TP impairment and the TMDL loading goals.

TP, DP, TSS, and total suspended sediment concentration data were obtained from NEW Water (the brand of the Green Bay Metropolitan Sewerage District), the WDNR, and the U.S. Geological Survey and combined into one dataset. All the TSS and total suspended sediment data were used together with no adjustment factor and are referred to as simply “TSS.” During WYs 1989–2021, mean annual TP concentrations increased from 0.089 milligram per liter (mg/L) at the Lake Winnebago outlet to 0.128 mg/L at the mouth of the Fox River, and concentrations decreased at all three sites from WY 1989 to WY 2021. The most recent (WYs 2017–21) median May–October TP concentrations were just less than the 0.1-mg/L WDNR criterion for TP impairment at the two upstream sites (Lake Winnebago outlet and De Pere) but were slightly greater than the criterion for impairment at the mouth of the Fox River. Mean annual DP concentrations increased from 0.024 mg/L at the Lake Winnebago outlet to 0.036 mg/L at the mouth of the Fox River. DP concentrations increased from WY 1989 to WY 2021 at the Lake Winnebago outlet but not at the other sites. Mean annual TSS concentrations increased from 13.5 mg/L at the Lake Winnebago outlet to 23.9 mg/L at the mouth of the Fox River and have decreased at all three sites from WY 1989 to WY 2021. The recent median May–October TSS concentrations were less than the 20-mg/L WDNR criterion for impairment at all three sites. Streamflow and TP, DP, and TSS loads increased from the Lake Winnebago outlet to the mouth of the Fox River (TP loads increased from 360,000 to 557,000 kilograms per year [kg/yr], DP loads increased from 114,000 to 162,000 kg/yr, and TSS loads increased from 60,400 metric tons per year [t/yr] to 122,600 t/yr).

At the Lake Winnebago outlet, DP concentrations and TP and DP loads increased from WY 1989 to WY 2021 because of an increase in DP concentrations in Lake Winnebago resulting from the lake becoming nitrogen limited as a result of biological processes not consuming the DP in the lake and an increase in streamflow leaving the lake. Although TP and TSS concentrations decreased at De Pere and the mouth of the Fox River, there was little change in the loading because of an increase in flow. Flow-normalized TP and TSS loads at De Pere and the mouth of the Fox River decreased possibly because of implementation of agricultural conservation management practices, reductions in point-source discharges in its drainage basin, and deposition of sediment and phosphorus in recently dredged areas of the Lower Fox River. Additional studies are needed to determine the relative importance of each of these actions and whether the decrease in concentrations and flow-normalized loads will continue to be observed in the Fox River.
