Isotopic evaluation of the National Water Model reveals missing agricultural irrigation contributions to streamflow across the western United States

The National Water Model (NWM) provides critical analyses and projections of streamflow that support water management decisions. However, the NWM performs poorly in lower-elevation rivers of the western United States (US). The accuracy of the NWM depends on the fidelity of the model inputs and the representation and calibration of model processes and water sources. To evaluate the NWM performance in the western US, we compared observations of river water isotope ratios (¹⁸O /"> ¹⁶O and ²H /"> ¹H expressed in δ notation) to NWM-flux-estimated (model) river reach isotope ratios. The modeled estimates were calculated from long-term (2000–2019) mean summer (June, July, and August) NWM hydrologic fluxes and gridded isotope ratios using a mass balance approach. The observational dataset comprised 4503 in-stream water isotope observations in 877 reaches across 5 basins. A simple regression between observed and modeled isotope ratios explained 57.9 % (δ¹⁸O) and 67.1 % (δ²H) of variance, although observations were 0.5 ‰ (δ¹⁸O) and 4.8 ‰ (δ²H) higher, on average, than mass balance estimates. The unexplained variance suggest that the NWM does not include all relevant water fluxes to rivers. To infer possible missing water fluxes, we evaluated patterns in observation–model differences using δ¹⁸O_diff (δ¹⁸O_obs−δ¹⁸O_mod) and d_diff (δ2Hdiff-8⋅δ18Odiff">). We detected evidence of evaporation in observations but not model estimates (negative d_diff and positive δ¹⁸O_diff) at lower-elevation, higher-stream-order, arid sites. The catchment actual-evaporation-to-precipitation ratio, the fraction of streamflow estimated to be derived from agricultural irrigation, and whether a site was reservoir-affected were all significant predictors of d_diff in a linear mixed-effects model, with up to 15.2 % of variance explained by fixed effects. This finding is supported by seasonal patterns, groundwater levels, and isotope ratios, and it suggests the importance of including irrigation return flows to rivers, especially in lower-elevation, higher-stream-order, arid rivers of the western US.
