Simulation of groundwater flow in the Long Island, New York regional aquifer system for pumping and recharge conditions from 1900 to 2019
The U.S. Geological Survey has developed a transient, groundwater-flow model that simulates hydrologic conditions in the Long Island aquifer system as part of an ongoing (since 2016) multiyear, cooperative investigation with the New York State Department of Environmental Conservation. The goals of this investigation are to assist stakeholders and resource managers to evaluate the response of the hydrologic system to changes in future hydraulic stresses. Responses in the hydrologic system include changes in water levels in the hydrogeologic units; discharge to streams, coastal waters, and subsurface infrastructure; and the extent of saline groundwater in the aquifers. Hydraulic stresses include future water-supply management and changes in land use and infrastructure.
The numerical model synthesizes a diverse set of physiographic, geologic, climatic, land-use, and historical population, water use, and infrastructure data to physically represent the Long Island aquifer system from land surface to bedrock and to simulate annual hydrologic conditions between 1900 and 2019. A three-dimensional hydrogeologic framework was developed from existing and recently collected borehole geologic and geophysical data collected as part of a companion drilling program. Water-transmitting properties of the principal aquifer sediments were defined in three dimensions from new and existing lithologic logs. The distribution of recharge from precipitation was estimated from landscape characteristics and climate data. Anthropogenic recharge from wastewater, leaky infrastructure, and storm runoff were estimated from population, infrastructure, and pumping data.
Water-use data, including well locations, depths, and pumping rates, were obtained from historical sources and records and used to estimate pumping stresses continuously in time and space, at an annual average time scale. The data were incorporated into a three-dimensional numerical model using the U.S. Geological Survey finite difference modeling code MODFLOW 6; the model encompassed all of Long Island and surrounding surface waters and simulated historical hydrologic conditions from 1900 to 2019.
The calibration process involved trial and error adjustments using prior knowledge to improve general fit to observations followed by an inverse calibration to update and optimize input parameters, using an iterative ensemble smoother algorithm implemented in PEST++ version 5.0. This resulted in a model that generally was in good agreement with observed, dynamically varying hydrologic conditions from 1900 to 2019. The calibrated model was used to develop two base-case models for scenario testing of future, hypothetical conditions where one represented average-annual conditions, and one represented average-seasonal conditions from 2010 to 2019. The model representing average-annual conditions was modified further to represent an alternate sea-level position of 6 feet above the North American Vertical Datum of 1988, and the model representing average-seasonal conditions was modified to represent the average seasonal effects of a 5-year drought imposed upon current hydrologic conditions.
Recharge is the sole source of water to the aquifer system; groundwater discharges to coastal water and streams and is withdrawn by pumped wells. Model-estimated annual recharge ranged from about 11 inches in 1965 to 41 inches in 1983. On average, from 2010 to 2019, about 23 percent of water was pumped from wells, and about 47 and 27 percent discharged to coastal waters and streams, respectively; the remaining 4 percent was water that moved into storage in the aquifer matrix.
Water levels on Long Island vary naturally during time in response to changes in recharge; the amount of variation is largest in the interior of the island, in areas with highest water table altitudes near groundwater divides and lowest near streams and the coastal waters. The total range of water table altitudes on Long Island between 1900 and 2019 ranged from near 0 to more than 70 feet in western parts of Long Island. The largest range in altitudes is in New York City and is associated with areas of large historical withdrawals between the 1920s and the late 1980s. Water table altitudes generally varied by less than 10 feet in eastern Suffolk County, where the aquifer is under more natural conditions.
Saltwater intrusion is of great concern on Long Island, particularly in western Long Island where both the unconfined and confined parts of the aquifer system have been intruded in response to large-scale groundwater withdrawals; however, the volume of freshwater in the islandwide aquifer system only has changed by about 5 percent between 1900 and 2019. The decadal change in the freshwater volume was largest during the early and mid-20th century, corresponding to the largest historical pumping, but that volume change did not exceed 1 percent.
The negligible change in freshwater volume suggests that saltwater intrusion as of 2019 was limited at an islandwide scale but continues to occur in local areas of Queens and Nassau Counties, adversely affecting current water supplies and limiting future water supplies for affected communities. The regional groundwater model developed for this investigation is a tool that can be used to help determine the viability of current and future water supplies at a regional scale and can be used to support development of additional models at finer scale to support more focused assessments of groundwater sustainability.
Citation Information
Publication Year | 2024 |
---|---|
Title | Simulation of groundwater flow in the Long Island, New York regional aquifer system for pumping and recharge conditions from 1900 to 2019 |
DOI | 10.3133/sir20245044 |
Authors | Donald A. Walter, Kalle L. Jahn, John P. Masterson, Sarken E. Dressler, Jason S. Finkelstein, Jack Monti, Jr. |
Publication Type | Report |
Publication Subtype | USGS Numbered Series |
Series Title | Scientific Investigations Report |
Series Number | 2024-5044 |
Index ID | sir20245044 |
Record Source | USGS Publications Warehouse |
USGS Organization | New York Water Science Center |
