Altitudes and Thicknesses of Hydrogeologic Units of the Ozark Plateaus Aquifer System in Arkansas, Kansas, Missouri, and Oklahoma

A hydrogeologic framework was constructed to represent the altitudes and thicknesses of hydrogeologic units within the Ozark Plateaus aquifer system (hereinafter referred to as the Ozark system). The Ozark system study area is nearly 70,000 square miles and includes parts of Arkansas, Kansas, Missouri, and Oklahoma. Nine hydrogeologic units were selected for delineation within the Ozark system and included the Western Interior Plains confining system, Springfield Plateau aquifer, the Ozark confining unit, Ozark aquifer which was divided into the upper, middle, and lower Ozark aquifers to better capture the spatial variation in the hydrologic properties, the St. Francois confining unit, the St. Francois aquifer, and the Basement confining unit. The formations that make up the hydrogeologic units of the Ozark system range from Pennsylvanian to Cambrian age. The scope of effort included the compilation and interpretation of hydrogeologic altitudes from geophysical, lithologic driller description, and well cutting logs. The final compiled dataset included more than 23,000 individual altitude points (excluding synthetic points) representing the nine hydrogeologic units. The hydrogeologic framework was developed in part for a groundwater flow model supported by the U.S. Geological Survey Water Availability and Use Science Program to aid in the understanding of groundwater availability.
