In order to construct the borehole extensometer at West Point, 1420 feet of 7 inch steel casing was fed into the ground using the drilling rig, as pictured here. This steel casing allows the borehole to hold its shape and not collapse in on itself, and isolates the 2 inch thick extensometer rod from the surrounding sediments.
Drilling for the West Point Borehole Extensometer
Detailed Description
Drilling a new borehole extensometer is a delicate task. The USGS Research Drilling Team worked with the researchers from Virginia Land Motion program to drill the 1420-foot-deep borehole for the extensometer at West Point.
